Maven 是一个优秀的项目构建和管理工具，mybatis-generator 插件用于快速生成 Mybatis xml 与实体 Bean。

分为三步，在pom.xml中做两处配置，第二步创建generatorConfig.xml，第三步运行执行命令生成代码

##### 1 mybatis-generator 插件 Maven 配置 #####

首先在你项目的 pom.xml 中配置插件

<build>
            <plugins>
                <plugin>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-maven-plugin</artifactId>
                </plugin>

                <plugin>
                    <groupId>org.mybatis.generator</groupId>
                    <artifactId>mybatis-generator-maven-plugin</artifactId>
                    <version>1.3.2</version>
                    <configuration>
                        <configurationFile>${
        basedir}/src/main/resources/generator/generatorConfig.xml</configurationFile>
                        <overwrite>true</overwrite>
                        <verbose>true</verbose>
                    </configuration>

                    <dependencies>
                        <dependency>
                            <groupId>mysql</groupId>
                            <artifactId>mysql-connector-java</artifactId>
                            <version>5.1.40</version>
                        </dependency>
                        <dependency>
                            <groupId>org.mybatis.generator</groupId>
                            <artifactId>mybatis-generator-core</artifactId>
                            <version>1.4.0</version>
                        </dependency>
                    </dependencies>
                </plugin>

            </plugins>
        </build>

##### 2 mybatis-generator 插件 配置文件创建 #####

在第一步中 我们通过 configurationFile 标签配置了 mybatis-generator 使用的配置文件。

<configurationFile>...generatorConfig.xml</configurationFile>

所以第二步就是创建配置文件

![在这里插入图片描述][watermark_type_ZmFuZ3poZW5naGVpdGk_shadow_10_text_aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3psMTg2MDM1NDM1NzI_size_16_color_FFFFFF_t_70]

<?xml version="1.0" encoding="UTF-8"?>
    <!DOCTYPE generatorConfiguration
            PUBLIC "-//mybatis.org//DTD MyBatis Generator Configuration 1.0//EN"
            "http://mybatis.org/dtd/mybatis-generator-config_1_0.dtd">

    <generatorConfiguration>
        <context id="DB2Tables" targetRuntime="MyBatis3">

            <commentGenerator>
                <property name="suppressDate" value="true"/>

                <property name="suppressAllComments" value="true"/>
            </commentGenerator>


            <jdbcConnection driverClass="com.mysql.jdbc.Driver"
                            connectionURL="jdbc:mysql://localhost:3306/test_mybatis"
                            userId="zhaolong"
                            password="123456">
            </jdbcConnection>


            <javaTypeResolver>

                <property name="forceBigDecimals" value="false"/>
            </javaTypeResolver>


            <javaModelGenerator targetPackage="com.example.demo.m" targetProject="src/main/java">
                <property name="enableSubPackages" value="true"/>
                <property name="trimStrings" value="true"/>
            </javaModelGenerator>


            <sqlMapGenerator targetPackage="mappers" targetProject="src/main/resources">
                <property name="enableSubPackages" value="true"/>
            </sqlMapGenerator>


            <javaClientGenerator type="XMLMAPPER" targetPackage="com.example.demo.m" targetProject="src/main/java">
                <property name="enableSubPackages" value="true"/>
            </javaClientGenerator>


            <table tableName="t_user" domainObjectName="User" enableCountByExample="false" enableUpdateByExample="false"
                   enableDeleteByExample="false" enableSelectByExample="false" selectByExampleQueryId="false">
                <property name="useActualColumnNames" value="false"/>

                <generatedKey column="id" sqlStatement="Mysql" identity="true"/>
            </table>
        </context>

    </generatorConfiguration>

大家在使用时，直接复制我这个配置文件，然后修改里面的数据库连接以及要生成的表的 tableName就可以了。

##### 3 第三步就是执行命令生成代码 #####

![在这里插入图片描述][watermark_type_ZmFuZ3poZW5naGVpdGk_shadow_10_text_aHR0cHM6Ly9ibG9nLmNzZG4ubmV0L3psMTg2MDM1NDM1NzI_size_16_color_FFFFFF_t_70 1]
生成的 User.java 文件内容如下

public class User {

        private Long id;

        private String idCard;

        private String uName;

        private String uPhone;

        private Integer uAge;

        private String uImage;

        private Date createTime;

         ... get set 方法省略

    }

生成的 UserMapper.java 文件内容如下

public interface UserMapper {

        int deleteByPrimaryKey(Long id);

        int insert(User record);

        int insertSelective(User record);

        User selectByPrimaryKey(Long id);

        int updateByPrimaryKeySelective(User record);

        int updateByPrimaryKey(User record);
    }

生成的 UserMapper.xml 文件内容如下

<?xml version="1.0" encoding="UTF-8"?>
    <!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
    <mapper namespace="com.example.demo.m.UserMapper">
      <resultMap id="BaseResultMap" type="com.example.demo.m.User">
        <id column="id" jdbcType="BIGINT" property="id" />
        <result column="id_card" jdbcType="VARCHAR" property="idCard" />
        <result column="u_name" jdbcType="VARCHAR" property="uName" />
        <result column="u_phone" jdbcType="VARCHAR" property="uPhone" />
        <result column="u_age" jdbcType="INTEGER" property="uAge" />
        <result column="u_image" jdbcType="VARCHAR" property="uImage" />
        <result column="create_time" jdbcType="TIMESTAMP" property="createTime" />
      </resultMap>
      <sql id="Base_Column_List">
        id, id_card, u_name, u_phone, u_age, u_image, create_time
      </sql>
      <select id="selectByPrimaryKey" parameterType="java.lang.Long" resultMap="BaseResultMap">
        select
        <include refid="Base_Column_List" />
        from t_user
        where id = #{
        id,jdbcType=BIGINT}
      </select>
      <delete id="deleteByPrimaryKey" parameterType="java.lang.Long">
        delete from t_user
        where id = #{
        id,jdbcType=BIGINT}
      </delete>
      <insert id="insert" parameterType="com.example.demo.m.User">
        <selectKey keyProperty="id" order="AFTER" resultType="java.lang.Long">
          SELECT LAST_INSERT_ID()
        </selectKey>
        insert into t_user (id_card, u_name, u_phone,
          u_age, u_image, create_time
          )
        values (#{
        idCard,jdbcType=VARCHAR}, #{
        uName,jdbcType=VARCHAR}, #{
        uPhone,jdbcType=VARCHAR},
          #{
        uAge,jdbcType=INTEGER}, #{
        uImage,jdbcType=VARCHAR}, #{
        createTime,jdbcType=TIMESTAMP}
          )
      </insert>
      <insert id="insertSelective" parameterType="com.example.demo.m.User">
        <selectKey keyProperty="id" order="AFTER" resultType="java.lang.Long">
          SELECT LAST_INSERT_ID()
        </selectKey>
        insert into t_user
        <trim prefix="(" suffix=")" suffixOverrides=",">
          <if test="idCard != null">
            id_card,
          </if>
          <if test="uName != null">
            u_name,
          </if>
          <if test="uPhone != null">
            u_phone,
          </if>
          <if test="uAge != null">
            u_age,
          </if>
          <if test="uImage != null">
            u_image,
          </if>
          <if test="createTime != null">
            create_time,
          </if>
        </trim>
        <trim prefix="values (" suffix=")" suffixOverrides=",">
          <if test="idCard != null">
            #{
        idCard,jdbcType=VARCHAR},
          </if>
          <if test="uName != null">
            #{
        uName,jdbcType=VARCHAR},
          </if>
          <if test="uPhone != null">
            #{
        uPhone,jdbcType=VARCHAR},
          </if>
          <if test="uAge != null">
            #{
        uAge,jdbcType=INTEGER},
          </if>
          <if test="uImage != null">
            #{
        uImage,jdbcType=VARCHAR},
          </if>
          <if test="createTime != null">
            #{
        createTime,jdbcType=TIMESTAMP},
          </if>
        </trim>
      </insert>
      <update id="updateByPrimaryKeySelective" parameterType="com.example.demo.m.User">
        update t_user
        <set>
          <if test="idCard != null">
            id_card = #{
        idCard,jdbcType=VARCHAR},
          </if>
          <if test="uName != null">
            u_name = #{
        uName,jdbcType=VARCHAR},
          </if>
          <if test="uPhone != null">
            u_phone = #{
        uPhone,jdbcType=VARCHAR},
          </if>
          <if test="uAge != null">
            u_age = #{
        uAge,jdbcType=INTEGER},
          </if>
          <if test="uImage != null">
            u_image = #{
        uImage,jdbcType=VARCHAR},
          </if>
          <if test="createTime != null">
            create_time = #{
        createTime,jdbcType=TIMESTAMP},
          </if>
        </set>
        where id = #{
        id,jdbcType=BIGINT}
      </update>
      <update id="updateByPrimaryKey" parameterType="com.example.demo.m.User">
        update t_user
        set id_card = #{
        idCard,jdbcType=VARCHAR},
          u_name = #{
        uName,jdbcType=VARCHAR},
          u_phone = #{
        uPhone,jdbcType=VARCHAR},
          u_age = #{
        uAge,jdbcType=INTEGER},
          u_image = #{
        uImage,jdbcType=VARCHAR},
          create_time = #{
        createTime,jdbcType=TIMESTAMP}
        where id = #{
        id,jdbcType=BIGINT}
      </update>
    </mapper>

--------------------

完毕
